12 Volt DC Motor – 200 RPM

           Ask for Latest offer / Availability :https://bit.ly/3dOYxKE

    1. Operating Voltage(V): 12
    2. Rated Speed (RPM): 200
    3. Rated Torque(kg-cm): 1.5
    4. Stall Torque(kg-cm): 5.4
    5. Load Current (A): 0.3
    6. No Load Current (A): 0.06

185.00 299.00 incl. GST

These motors are simple DC Motors featuring gears for the shaft for obtaining the optimal performance characteristics. They are known as Center Shaft DC Geared Motors because their shaft extends through the center of their gearbox assembly.

These standard size DC Motors are very easy to use. Also, you don’t have to spend a lot of money to control motors with an Arduino or compatible board. The L298N H-bridge module with an onboard voltage regulator motor driver can be used with this motor that has a voltage of between 5 and 35V DC.

This 12V DC Motor – 200RPM can be used in all-terrain robots and a variety of robotic applications. These motors have a 3 mm threaded drill hole in the middle of the shaft thus making it simple to connect it to the wheels or any other mechanical assembly.

Nut and threads on the shaft to easily connect and internally threaded shaft for easily connecting it to the wheels.

These DC Geared motors with robust metal/Plastic gearbox for heavy-duty applications, available in the wide RPM range(Check the list below) and ideally suited for robotics and industrial applications.


1. This motor is available in white and black colors. Please note you will get any one of them randomly.

2. Depending upon the Manufacturer given dimensions may vary in the range of ±5%.

We are supplying the range of such Center Shaft DC Motors, you can choose one according to your requirement by clicking on the RPM below

3        –     16 kg-cm
10      –     7 kg-cm
30     –     5 kg-cm
60     –     3.6 kg-cm
100   –     2.9 kg-cm
150    –     2 kg-cm
200   –    1.5 kg-cm
300   –    1.2 kg-cm
500   –    0.7 kg-cm

Features :

  1. It comes with Good Quality Gears.
  2. The metal gears have better wear and tear properties.
  3. The gearbox is sealed and lubricated with lithium grease and requires no maintenance.
  4. Although the motor gives 200 RPM at 12V, the motor runs smoothly from 4V to 12V and gives a wide range of RPM, and torque.
  5. The shaft has a hole for better coupling.

Package Includes :

1 x 12 Volt DC Motor – 200 RPM

RPM – 200 Shaft

Diameter – 6mm (with internal hole)

Weight – 125gms

Torque – 4 kgcm

Voltage – 6 to 24 (Nominal Voltage – 12v)

No-load current = 60 mA(Max), Load current = 300 mA(Max)
